X91 Powerful Rectangular Electromagnetic Chuck

1. Type: Electromagnetic chuck

2. Dimensions: Standard size or Customized

3. Suction force: ≧ 150 N/cm²
4. Rated Voltage : 110 V
5. Application: Millin maching and planing maching
6. Features:Powerful suction,safe and reliable to use

INQUIRE now
  • Product Detail
  • Technical Specifications
Powerful rectangular electromagnetic chuck is used for milling machine and planing machine.With strong magnetic force and reliable performance,X91 series electromagnetic chuck is extraordianrily convenient for workpieces not suitable for mechanical fixture.

The holding force is above 150N/cm².

Features of X91 series - Powerful rectangular electromagnetic chuck
1. Suction force well-distributed
2. Position reliable
3. Easy to operate
4. Suitable for heavey duty cutting processing
5. Improve the processing efficiency by more than 80%

Specifications of X91 series -  Powerful rectangular electromagnetic chuck
Model Dimensions (mm) Pole Pitch (mm) Current (A) Power (W) Net weight (KG)
X91 200×560 560x200x108 22(18+4) 1.6 176 65
X91 200×630 630x200x108 22(18+4) 1.6 176 70
X91 300×680 600x300x110 22(18+4) 2.2 242 120
X91 300×800 800x300x100 22(18+4) 3 330 135
X91 300×1000 1000x300x110 22(18+4) 3.2 352 160
X91 300×1000 1000x300x120 39(33+6) 4 440 180
X91 320×800 800x320x110 22(18+4) 3 330 145
X91 320×1000 1000x320x110 22(18+4) 4 440 175
X91 320×1250 1250x320x110 22(18+4) 4.5 495 225
X91 320×1600 1600x320x115 22(18+4) 5 550 240
X91 400×800 800x400x110 22(18+4) 3 330 180
X91 400×1000 1000x400x110 22(18+4) 4 440 240
X91 400×1000 1000x400x120 39(33+6) 5 550 255
X91 400×1250 1250x400x120 22(18+4) 5 550 250
X91 500×1000 1000x500x110 22(18+4) 8 880 290
X91 500×2000 200x500x120 22(18+4) 10 1100 580
X91 500×1000 1000x500x110 22(18+4) 5 550 280
X91 600×1000 1000x600x110 22(18+4) 6 660 340
X91 600×1000 1000x600x120 39(33+6) 8 880 350
X91 800×1000 1000x800x120 39(33+6) 10 1100 580

Notes on the use of electromagnet

1. The Electromagnetic chuck should be supplied with rated voltage of 110 volts DC power. The rectifier and control device is already equiped in the host electrical equipment if used on grinding machine. If use alone can select sets of rectifying device directly.

2. There must be a cooling liquid under the condition of grinding,to avoid the workpieces so overheated that influence the precision of the working surface,or lead to burn out the coil.

3. The contact surface between the workpiece and the panel should not less than one pole pitch, in order to make full use of the chuck's magnetic force.

4. After the chuck fixed on the machine,should self grinding one time to ensure the accuracy. If the working surface change rough or magnetic force decreased,can self grinding the working surface to ensure that the magneitc force will not decline.
