Magnetic Liquid Traps With Clamp Connection
Magnetic Liquid Traps With Clamp Connection Magnetic Liquid Traps With Clamp Connection Magnetic Liquid Traps With Clamp Connection Magnetic Liquid Traps With Clamp Connection Magnetic Liquid Traps With Clamp Connection

Magnetic Liquid Traps With Clamp Connection

1. Type: Magnetic Liquid Traps / Filters With Clamp Connection

2. Diameter of magnetic bar: D25mm standard or Customized

3. Material: NdFeB/Ferrite/Smco + SUS304/SUS316L Stainless Steel
4. Surface magnetic force: 2000 GS to 8000 GS

5. Max working temp.: Max 80℃-350℃

6. Surface treatment: Well polishing,Sand blasting,Abrasion resistance solution.

INQUIRE now
  • Product Detail
  • Technical Specifications
Magnetic liquid traps or Magnetic liquid filters are designed for liquid or semi-liquid flow systems to remove ferrous contamination from liquid with different viscosity level.They preserve product purity by removing small contaminants,provide magnetic protection for liquid lines and processing equipments.

Types Of Magnetic Liquid Traps With Clamp Connection
1. Normal style magnetic liquid tarp
2. Easy clean magnetic liquid tarp

Features Of Magnetic Liquid Traps With Clamp Connection
1. The maximum magnetic strength can reach to 12000GS for Normal style,8000GS for easy clean style.
2. Standard working temperature≤80ºC,and maximum working temperature can reach to 350ºC.
4. Easy installation,separation and cleaning.
5. SUS304 or SUS316L stainless steel are available.
6. Ideal designed magnetic configuration ensures maximum magnetic effect without liquid flow impediment.
7. Special design for high pressure or flow rate is available.

Specifications Of Magnetic Liquid Traps With Clamp Connection,Normal Style


Model Size Diameter of
magnetic bar 		Numbers of
magnetic bar
D d Φ H L
NMLT-100/25C 100 25.4 50.5 150 220 25 mm 3 bars
NMLT-100/38C 100 38.1 50.5 150 220 25 mm 3 bars
NMLT-100/50C 100 50.8 64 150 220 25 mm 3 bars
NMLT-100/63.5C 100 63.5 77.5 150 220 25 mm 3 bars
NMLT-100/76C 100 76.2 91 150 220 25 mm 3 bars
NMLT-114/25C 114 25.4 50.5 150 250 25 mm 5 bars
NMLT-114/38C 114 38.1 50.5 150 250 25 mm 5 bars
NMLT-114/50C 114 50.8 64 150 250 25 mm 5 bars
NMLT-114/63.5C 114 63.5 77.5 150 250 25 mm 5 bars
NMLT-114/76C 114 76.2 91 150 250 25 mm 5 bars
NMLT-150/25C 150 25.4 50.5 150 300 25 mm 5 bars
NMLT-150/38C 150 38.1 50.5 150 300 25 mm 5 bars
NMLT-150/50C 150 50.8 64 150 300 25 mm 5 bars
NMLT-150/63.5C 150 63.5 77.5 150 300 25 mm 5 bars
NMLT-150/76C 150 76.2 91 150 300 25 mm 5 bars
NMLT-150/100C 150 101.6 119 150 300 25 mm 5 bars
NMLT-200/25C 200 25.4 50.5 200 360 25 mm 7 bars
NMLT-200/38C 200 38.1 50.5 200 360 25 mm 7 bars
NMLT-200/50C 200 50.8 64 200 360 25 mm 7 bars
NMLT-200/63.5C 200 63.5 77.5 200 360 25 mm 7 bars
NMLT-200/76C 200 76.2 91 200 360 25 mm 7 bars
NMLT-200/100C 200 101.6 119 200 360 25 mm 7 bars

Specifications Of Magnetic Liquid Traps With Clamp Connection,Easy Clean Style

Model Size Diameter of
magnetic bar 		Numbers of
magnetic bar
D d Φ H L
EMLT-100/25C 100 25.4 50.5 150 220 25 mm 3 bars
EMLT-100/38C 100 38.1 50.5 150 220 25 mm 3 bars
EMLT-100/50C 100 50.8 64 150 220 25 mm 3 bars
EMLT-100/63.5C 100 63.5 77.5 150 220 25 mm 3 bars
EMLT-100/76C 100 76.2 91 150 220 25 mm 3 bars
EMLT-114/25C 114 25.4 50.5 150 250 25 mm 5 bars
EMLT-114/38C 114 38.1 50.5 150 250 25 mm 5 bars
EMLT-114/50C 114 50.8 64 150 250 25 mm 5 bars
EMLT-114/63.5C 114 63.5 77.5 150 250 25 mm 5 bars
EMLT-114/76C 114 76.2 91 150 250 25 mm 5 bars
EMLT-150/25C 150 25.4 50.5 150 300 25 mm 5 bars
EMLT-150/38C 150 38.1 50.5 150 300 25 mm 5 bars
EMLT-150/50C 150 50.8 64 150 300 25 mm 5 bars
EMLT-150/63.5C 150 63.5 77.5 150 300 25 mm 5 bars
EMLT-150/76C 150 76.2 91 150 300 25 mm 5 bars
EMLT-150/100C 150 101.6 119 150 300 25 mm 5 bars
EMLT-200/25C 200 25.4 50.5 200 360 25 mm 7 bars
EMLT-200/38C 200 38.1 50.5 200 360 25 mm 7 bars
EMLT-200/50C 200 50.8 64 200 360 25 mm 7 bars
EMLT-200/63.5C 200 63.5 77.5 200 360 25 mm 7 bars
EMLT-200/76C 200 76.2 91 200 360 25 mm 7 bars
EMLT-200/100C 200 101.6 119 200 360 25 mm 7 bars

Specifications of Magnetic Bars/Tubes/Rods
Magnetic
Force
 Diameter 		4000GS 5000GS 6000GS 7000GS 8000GS 10000GS 11000GS 12000GS
Φ6(0.24") √UH － － － － － － －
Φ8(0.31") √UH － － － － － － －
Φ9(0.35") √UH － － － － － － －
Φ10(0.39") √UH － － － － － － －
Φ12(0.47") √UH √UH － － － － － －
Φ16(0.63") √UH √UH √UH － － － － －
Φ19(0.75") √UH √UH √UH √UH － － － －
Φ20.3(0.80") √UH √UH √UH √UH － － － －
Φ22(0.85") √UH √UH √UH √UH √UH － － －
Φ25(1.00") √UH √UH √UH √UH √UH √UH √N √N
Φ32(1.25") √UH √UH √UH √UH √UH √UH √N √N
Φ38(1.50") √UH √UH √UH √UH √UH √UH √N √N
Φ50(1.75") √UH √UH √UH √UH √UH √UH √N √N
Φ63(2.48") √UH √UH √UH √UH √UH √UH √N √N
