Easy Clean Magnetic Drawer For Powders Permanent Magnetic Separator

1. Type: Easy clean magnetic drawer separation

2. Diameter of magnetic bar: D25mm standard or Customized

3. Material: NdFeB/Ferrite/Smco + SUS304/SUS316L Stainless Steel
4. Surface magnetic force: 2000 GS to 8000 GS

5. Max working temp.: Max 80℃-350℃
6. Type: Rctangular or round shape series

7. Surface treatment: Well polishing,Sand blasting,Abrasion resistance solution.

INQUIRE now
  • Product Detail
  • Technical Specifications
Easy clean magnetic drawer separation (also name housed grid magnetic separation,drawer magnet) is designed to remove ferromagnetic impurities,weak magnetic iron contaminants and others in free-flowing,externally-conveyed materials (such as pellets and powders and other small paramagnetic particles),which can effectively purify the material,improve material quality,and protect the downstream equipment from the damage of the ferrous,to ensure the efficient operation of processing equipment.

Types Of Magnetic Drawer Separations
1. Normal magnetic drawer
2. Easy-cleaning magnetic drawer
3. Self-cleaning magnetic drawer

Features Of Easy Clean Magnetic Drawer Separations
1. The house is stainless steel with seal.
2. Easy to clean and with high collection capacity.
3. Permanent and Powerful magnetic force,max surface magnetic power upto 8000 Gauss.
4. Temperature resistance up to 350℃
5. Single-layer or multi-layer optional,multiple layers preferable bring better separation effect.
6. Varied connection methods such as clamp,round or rectangular flanges,or customized to meet the requirement of pipe interface.
7. Can be customized on request or the drawing.

Specifications Of Easy Clean Magnetic Drawer Separations

Model Flange Type A B C D F G
Dia. of
magnetic bar
Layers of
magnetic grid
Numbers of
magnetic bar
EMDS102 As required 160 160 370 110 50 70 25 mm 2 5
EMDS103 440 50 70 25 mm 3 8
EMDS202 As required 220 220 370 161 50 70 25 mm 2 7
EMDS203 440 50 70 25 mm 3 11
EMDS302 As required 270 270 370 222 50 70 25 mm 2 9
EMDS303 440 50 70 25 mm 3 14
EMDS402 As required 330 330 370 276 50 70 25 mm 2 11
EMDS403 440 50 70 25 mm 3 17
EMDS502 As required 380 380 370 328 50 70 25 mm 2 13
EMDS503 440 50 70 25 mm 3 20
Provide customized magetic drawer as your requirements.
Specifications of Magnetic Bars/Tubes/Rods
Magnetic
Force
 Diameter 		4000GS 5000GS 6000GS 7000GS 8000GS 10000GS 11000GS 12000GS
Φ6(0.24") √UH － － － － － － －
Φ8(0.31") √UH － － － － － － －
Φ9(0.35") √UH － － － － － － －
Φ10(0.39") √UH － － － － － － －
Φ12(0.47") √UH √UH － － － － － －
Φ16(0.63") √UH √UH √UH － － － － －
Φ19(0.75") √UH √UH √UH √UH － － － －
Φ20.3(0.80") √UH √UH √UH √UH － － － －
Φ22(0.85") √UH √UH √UH √UH √UH － － －
Φ25(1.00") √UH √UH √UH √UH √UH √UH √N √N
Φ32(1.25") √UH √UH √UH √UH √UH √UH √N √N
Φ38(1.50") √UH √UH √UH √UH √UH √UH √N √N
Φ50(1.75") √UH √UH √UH √UH √UH √UH √N √N
Φ63(2.48") √UH √UH √UH √UH √UH √UH √N √N
