Alnico Horseshoe Magnet Red Paint U Shaped Alnico Magnet

1. Material: Red Paint Alnico Horseshoe Magnet

2. Shape: U Shape

3. Dimensions: As required / Customized

4. Grade: Alnico 5,Alnico 8,Alnico 9 and etc.

Click here to check the grade of alnico magnet

5. Coating: Without treatment or Red painting

6. Magnetized: As Request

7. Max working Temp.: 450 ℃-550 ℃
8. Tolerance: +/-0.05mm or +/-0.1mm

INQUIRE now
  • Product Detail
  • Technical Specifications
According to different production processes,alnico magnet is divided into cast alnico magnet and sintered alnico magnet.Compared to the cast alnico magnet,the sintered alnico magnet is limited to a small size,and the resulting blank materials has a dimensional tolerance that is better than that of the cast alnico magnet,and the magnetic properties are slightly lower than the cast alnico magnet,but processability is better.

The shape of the alnico magnet is mostly round and square,but irregular shapes can be customized on request.
The casting process (cast alnico magnet) can be processed into different sizes and shapes.

In permanent magnet material,cast alnico magnets have the lowest reversible temperature coefficient and can operate at temperatures up to 550 ℃.

Specifications of U shape alnico horseshoe magnet

Model A (mm) B(mm) C(mm) D(mm) Pull Force(KG)
LUA401 22.2 25.4 8.2 6.7 2.4
LUA402 23.1 25 6.5 6.5 1.8
LUA403 27 35 15.9 7.9 4
LUA404 41.3 39.7 15.9 9.5 6.8




Model A (mm) B(mm) C(mm) D(mm) E(mm) F(mm) Pull Force(KG)
LUA501 28 25 8 7 14 / 1.2
LUA502 60 60 10 30 25 6.5 5
LUA503 56 46 25 320 28 5.5 148
LUA504 62 51 24 30 31 7 17
LUA505 86 70 45 54 43 9.5 35

Model A (mm) B(mm) C(mm) D(mm) E(mm) F(mm) Pull Force(KG)
LUA601 22 17 25 8 8 7 4.5
LUA602 30 20 20 15 9 4 5
LUA603 40 25 25 20 11.5 5 9.2
LUA604 45 30 30 23 13 5 11.8
LUA605 57 35 40.5 27.8 12 7.9x2 25
LUA606 60.3 39.7 61.9 31.8 13 6.5 35
LUA607 63.5 46 47.6 34.9 16 4.8 33
LUA608 70 41.3 57.2 34.1 16 7.9x2 37
LUA609 70 34 40 44 14 6.5x2 23
LUA610 79.4 54 82.6 38.5 18 9.5x2 50
LUA611 79.4 54 85.7 47.6 18 / 60
LUA612 127 98 48 70 40 11x2 60

Application of alnico magnet
1. Quick Die Change System
2. Electric motors
3. Electric guitar pickups
4. Microphones
5. Sensors
6. Speakers
7. Traveling wave tubes
8. Animal husbandry
9. Teaching equipments

Characteristics of alnico magnet
1. Crystal density,high strength
2. Stong corrosion resistance
3. Uniform composition,excellent magnetic properities
4. Good temperature stability
5. Maximum working temperature up to 550 ℃

Magnetic Properties Of Cast Alnico Magnet
Grade MMPA
Equivalent
Class 		 Remanence
(Br) 		Coercive Force (Hcb) Maximum Energy Products
(BH)max 		Curie Temp.
Tc. 		Max
Working Temp.
Tw. 		Reversible Temp. Coefficient
a(Br)
T kGs KA/m kOe Kj/m³ MGO [°C] [°C] [%°C]
Isotropic *LN9 Alnico3 0.69 6.9 37 0.47 9 1.13 810 450 -0.03
*LN10 0.6 6 40 0.5 10 1.25 -0.03
*LNG12 Alnico2 0.72 7.2 44 0.55 12 1.5 -0.03
*LNG13 0.7 7 48 0.6 13 1.63 -0.03
*LNGT18 Alnico7 0.58 5.8 90 1.13 18 2.2 860 550 -0.03
Anisotropic LNG37 Alnico5 1.2 12 48 0.6 37 4.65 850 525 -0.02
LNG40 1.25 12.5 48 0.6 40 5 -0.02
LNG44 1.25 12.5 52 0.65 44 5.5 -0.02
LNG48 Alnico5DG 1.25 12.5 52 0.65 48 6 -0.02
LNG52 1.3 13 56 0.7 52 6.5 -0.02
LNG60 Alnico5～7 1.35 13.5 56 0.7 60 7.5 -0.02
LNGT28 Alnico6 1.05 10.5 56 0.7 28 3.5 -0.02
LNGT32 Alnico8 0.8 8 100 1.25 32 4.25 860 550 -0.03
LNGT38 0.82 8.2 110 1.38 38 4.75 -0.03
LNGT44 0.88 8.8 120 1.5 44 5.5 -0.03
LNGT48 0.9 9 120 1.5 48 6 -0.03
LNGT36J Alnico8HC 1.1 11 120 1.5 88 11 -0.03
LNGT60 Alnico9 0.9 9 110 1.38 60 7.5 -0.03
LNGT72 1.05 10.5 112 1.41 72 9 -0.03
LNGT88 1.1 11 120 1.5 88 11 -0.03
LNGT92 1.1 11 120 1.5 82 10.25 -0.03

Magnetic Properties Of Sintered Alnico Magnet

Grade 		MMPA
Equivalent
Class 		 Remanence
(Br) 		Coercive Force (Hcb) Maximum Energy Products
(BH)max 		Curie Temp.
Tc. 		Max Working Temp.
Tw. 		Reversible Temp. Coefficient
a(Br)
T kGs KA/m kOe Kj/m³ MGO [°C] [°C] [%°C]
Isotropic *FLN10 S-Alnico3 0.65 6.5 52 0.65 10 1.25 750 450 -0.03
*FLNG12 S-Alnico2 0.72 7.2 52 0.65 12 1.5 -0.03
*LNGT18 S-Alnico7 0.6 6 92 1.15 18 2.25 860 550 -0.03
Anisotropic FLNG35 S-Alnico5 1.15 11.5 52 0.65 35 4.4 850 510 -0.02
FLNGT28 S-Alnico6 1.05 10.5 60 0.75 28 3.5 860 550 -0.02
FLNGT40 S-Alnico8 0.88 8.8 120 1.5 40 5 -0.02
FLNGT42 1 10 105 1.3 42 5.25 -0.02
FLNGT44 0.92 9.2 120 1.5 44 5.5 -0.02
FLNGT48 0.95 9.5 128 1.6 49.5 6.2 -0.02
FLNGT36J S-Alnico8HC 0.75 7.5 140 1.75 36 4.5 -0.02

Mechanical Physical Properties Of Cast Alnico Magnet
Curie Temperature 760-890℃
Max. Operating Temperature 450-550℃
Resistivity 47-54μOhm.cm
Vickers Hardness 520-630Hv
Density 6.9-7.3g/cm³
Relative Recoil Permeability 1.7-4.7μrec
Saturation Field Strength 2.7-6.3kOe/215-500kA/m
Temperature Coefficient of Remanence (Br) -0.025~-0.02%/℃
Temperature Coefficient of Remanence (Hcj) +0.01~0.03%/℃
